Ornamental pond

Not for swimming, which changes how it is classified.

Site data

Lot
10,000 sq ft
Existing footprint
1,486 sq ft
This proposal
no added footprint
Building coverage
14.9%
Front / side / rear
84.1′ / 17.1′ / 28.9′
Scale
1″ = 20′

measured off the compiled model · no engine diagnostics · sizes are placeholders until this is drawn on your lot

Put this on your lot

free · no sign-up · seconds

01

One sheet, from one model

These are not separate drawings kept in step by hand. They are projections of the same model, so a change to the model changes all of them at once. A proposal with no interior has nothing to elevate or section — so the engine produces one sheet and does not pad the set.

Sheet A-001 — Site plan

02

Why this passes — and what sends one back

  1. Setbacks measured to the new edge, not to the house — 17.1′ to the nearer side line here.
  2. The scale is written down (1″ = 20′), not left to be inferred from the page size.
  3. North arrow on the sheet.
  4. Existing dashed, proposed solid. This is the first thing read at the counter, and getting it backwards is a refusal on its own.
  5. The coverage arithmetic is shown, not just its result — 1,486 sq ft existing and nothing added, so coverage does not move.

What sends this one back

The barrier, not the pool

A pool drawing with no enclosing barrier is refused outright — water is not permitted without a fence around it. The engine here takes the same position: it will not build the sheet set until the barrier closes.

What the sky can’t see — you add these

  • Recorded easements — a pool cannot sit over a utility run
  • On unsewered lots: the well and septic positions that fix where water can even go

provide them and they go on the sheet · invented lines never do

03

Same lot, 6 ways

Every pool in this category is drawn on the identical lot, so the coverage numbers on the cards can be read against each other.

POOL 01Rectangular pooladds noneThe standard one, laid along the long axis of the yard.POOL 02Lap pooladds noneNarrow and long, for a yard that has length but no width.POOL 03Plunge pooladds noneSmall enough for a small lot and still deep enough to matter.POOL 04Pool with surroundadds nonePool plus the hard surface around it — count both against paving limits.POOL 05Standalone spaadds noneJust the hot tub, set against the house. Still needs the barrier.

What this is not

This page is a demonstration our engine drew — not a permit that was submitted and not a drawing that was approved. Structural calculations and Title 24 energy compliance have to be signed by a licensed engineer or a certified analyst: we hand those off and we do not stamp them. Decks and small wood structures mostly fall inside the prescriptive tables and need no stamp at all, which is why they are the cleanest category here.
