Pool with surround on a 10,000 sq ft demo lot — aerial
Pools & water · POOL 04
Pool with surround
Pool plus the hard surface around it — count both against paving limits.
Site data
- Lot
- 10,000 sq ft
- Existing footprint
- 1,486 sq ft
- This proposal
- no added footprint
- Building coverage
- 14.9%
- Front / side / rear
- 54.6′ / 32.0′ / 40.4′
- Scale
- 1″ = 20′
measured off the compiled model · no engine diagnostics · sizes are placeholders until this is drawn on your lot
Put this on your lot
free · no sign-up · seconds
One sheet, from one model
These are not separate drawings kept in step by hand. They are projections of the same model, so a change to the model changes all of them at once. A proposal with no interior has nothing to elevate or section — so the engine produces one sheet and does not pad the set.
Sheet A-001 — Site plan
Why this passes — and what sends one back
- Setbacks measured to the new edge, not to the house — 32.0′ to the nearer side line here.
- The scale is written down (1″ = 20′), not left to be inferred from the page size.
- North arrow on the sheet.
- Existing dashed, proposed solid. This is the first thing read at the counter, and getting it backwards is a refusal on its own.
- The coverage arithmetic is shown, not just its result — 1,486 sq ft existing and nothing added, so coverage does not move.
What sends this one back
The barrier, not the pool
A pool drawing with no enclosing barrier is refused outright — water is not permitted without a fence around it. The engine here takes the same position: it will not build the sheet set until the barrier closes.
